Restaurant Waist Height Turnstiles RFID Roadway Security Control

Restaurant Waist Height Turnstiles RFID Roadway Security Control

  • Restaurant Waist Height Turnstiles RFID Roadway Security Control
  • Restaurant Waist Height Turnstiles RFID Roadway Security Control
Restaurant Waist Height Turnstiles RFID Roadway Security Control
Product Details:
Place of Origin: China(mainland)
Brand Name: RS Security
Certification: ISO,FCC,SGS,RoHS,CE
Model Number: RS 218-1s
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: 1000usd
Packaging Details: wooden box
Delivery Time: 3-8workdays
Payment Terms: TT
Supply Ability: 3000pcs/month
Contact Now
Detailed Product Description
Series: Tripod Turnstile Product Name: Double Core Tripod Turnstile
Model: RS 218-1s Brand: RS Security
Material: 304 Stainless Steel Size: 520*480*980
High Light:

automatic systems turnstiles

,

security turnstile gate



Entra Turnstile Waist Height Turnstiles RFID Security Control Barrier





keywords:2015accessories,ac motor sliding gate controller,advertising,access control system glass door,aluminum fenceaccess control tripod turnstile,automatic barrier gate,access control turnstile,automatic barrier gate with single baraccessories,automatic boom barrier

2015advertising,ac motor sliding gate controller,aluminum fence,access control system glass door,automatic barrier gateaccess control tripod turnstile,automatic barrier gate with single bar,access control turnstile,automatic boom barrieraccessories,automatic gate



Main Technical Specifications:



1) Power voltage: AC220V±10V, 50Hz
2) Operation environment temperature: -25°C ~75°C
3) Relative humidity: less than 95%, not condensed.
4) Max. Passage width: ≤600mm
5) Passing speed: ≤40 person/m (IC/ID card)
6) Motor: 24V
7) Communication Distance: 1200M
8) Input Connection: +12V Level Signal or Pulse Wide>100ms DC12V pulse, Current>10Ma
9) Communication Connection: RS485 Communication
10) Material: SS304





Description:



  • The 3 arms can rotate in one or two directions, controlled by an access control system or push button at a reception desk school, it prevents unauthorized people to enter the restricted areas,
  • The electromagnet unlock when a valid signal is given to the motherboard, it allows authorizer to go through the passageway.
  • simple installation and economic model





Features


1. 304 Stainless steel .
2. With high speed, reliable, strong compatibility.
3. Durable mechanical system, long life.
4. Integrated with any type of readers such as IC, ID, bar code and even magnetic card.
5. Bi-directional passing or single way passing.
6. Fire-fighting and anti-emergency function to evacuate passers. Rod down automatically when power off.
7. Self-inspection and alarm.
8. Multi-working mode: forbidden, controlled or free passing optional.
9. Card-reading memory function.
10. LED Counting and Direction indicating. (Optional)
11. ISO 9001 Quality Assurance and CE certification.



Optional features



Counter:

Voice speech

Remote control





Applications:

High security places, factory, fitness club, prison, hotel lobby, school, port, exhibition hall.





Traffic type



Restaurant Waist Height Turnstiles RFID Roadway Security Control 0Restaurant Waist Height Turnstiles RFID Roadway Security Control 1





Specification



Material

304 stainless steel

Input voltage

220V AC220±10%

Size

520*480*980mm

Are length

510mm

Net weight

50kg/unit

Arm diameter

38mm

Motor

24V DC brush

Cooler fan

Optional

Communication interface

RS485

Thermostat

Optional

Transit speed

30-40 people/minute

Service life

5000,000 times

Close and open time

0.6S

Input interface

Relay signal, 12V level signal,

Clear passage width

550mm

Work environment

Indoor and outdoor (shelter)

Number of led lamp

1pcs



RS 218-1s





Competitive Advantage:



Our advantage:



  • We are a leading manufacturer of turnstile and speed gate in China.
  • We focus on pedestrian turnstile gates.
  • We keep stock for regular products and we can support small orders. Usually, our lead time is just 3 days.
  • Design products according to customers’ requirements.
  • Credibility: We are SGS certificated Supplier. Our customers are located over 50 countries
  • Gratitude: We cherish the business chance you give us and return you with quality products and good service.
  • Professional: We have been in this business for more than 8 years. We have a strong professional team with various experiences.
  • We keep doing new product development. Our goal is to enhance our competitive capacity constantly.
  • Price: very competitive price and good quality products
  • Quality: we do 100% inspection before the shipment.
  • Promise: we are always ready to take the responsibility if any loss caused to our customer due to our mistakes.

Restaurant Waist Height Turnstiles RFID Roadway Security Control 2

Restaurant Waist Height Turnstiles RFID Roadway Security Control 3



Restaurant Waist Height Turnstiles RFID Roadway Security Control 4
