| Place of Origin: | China(mainland) |
| Brand Name: | RS Security |
| Certification: | ISO,FCC,SGS,RoHS,CE |
| Model Number: | RS1008 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 2000USD |
| Packaging Details: | wooden box |
| Delivery Time: | 3-8workdays |
| Payment Terms: | TT |
| Supply Ability: | 3000pcs/month |
| Series: | Drop Arm Turnstile | Model: | RS 1008 |
|---|---|---|---|
| Brand: | RS Security | Product Name: | Drop Arm Turnstile |
| Material: | 304 Stainless Steel | Size: | 1200*165*980mm |
| High Light: | security barriers and gates,biometric access control system |
||
Automatic drop arm turnstile
Drop arm gate
Drop arm barrier
Barrier Arm Turnstile
Drop arm turnstile
Drop arm gate
Drop arm barrier
Barrier Arm Turnstiles
Specification
intelligent arm drop turnstile---can be compatible with IC card , ID card ,barcode card , fingerprint reading card recognition device used for staff, provide civilized , orderly access methods; effectively manage the access of staff . Can be widely used in the station, wharf subway , factories, office building , hotel , clubs, intelligent community , enterprises and institution that need intelligent access management.
The barrier arm turnstile is a perfect combination of aesthetic look and fast passage.
Normal close or normal open can be switched.
It provides standard or wide lane to meet different requirements for the lane width, the lane width can be 600-1200mm
Company infomation
RS Security Co.,Ltd is a Shenzhen China based company that is specialized in phy sical access control product,such as tripod turnstile,wasit height turnstile,flap gate,full height turnstile,swing gate and other access control relater products.Due to our constant development and inprovement thess years,we have won a good reputation both in china and oversea.So far,we have business partners in more than 50 countries in the world and the quantity keeps increasing.
On the basis of the reliable client teedback we continue inproving the quanlity and features of our product range.we sincerely hope t build a strong cooperation relationshipe with you on the basis of mutual benefit.
| Drop arm turnstile Specification : | |
| Interface parameters: | One RS485 interface; Two card reader signals (passive); One fire alarm signal |
| Material: | 304 stainless steel |
| Power: | AC220+ 10%, 50Hz |
| Driver Mode: | DC24V / 30W |
| Temperature of Working Environment: |
-30° ~60 ° |
| Humidity: | 95%, |
| Length of Gate Rod: | 500mm |
| Opening and Closing time: | 0.5second |
| Service Life: | 3 millions continuous rotation |
| Overall Dimensions: | 1400L x 162W x 980H (mm) |
| Weight: | 75KGS |
| Rotation of Gate: | Single-directional, bi-directional (optional) |
| Working Environment: | Indoor, outdoor (need rain-proof frame) |
| Protection Grade: | IP42 |
| Features | |
| 1. Self-inspection of fault and alarm indication function, convenient for maintenance and usage. | |
| 2. The rod is automatic fall when power is off and self-inspection when the electricity is on and automatic recovery to the locked status. |
|
| 3. Various kinds of working modes which can be optional, such as bi-directional card reader; Read card at one side while forbidden passing on the opposite side; Read card at one side while allow passing on other side; Passing through infrared sensor in single and bi-directional way, the rod will be lifted and fall the gate will be closed when detected the person is passed. And the working mode of gate is setting through main menu. | |
| The infrared sensor detected the pedestrian who read valid card has passed, it will be lifted the rod and closed the gate automatically or delay lift and fall after the pedestrian has passed, able to delayed 1~60 seconds which can be set through the main menu. |
|
| 4. Able to reset automatically. If the pedestrian read the card but did not pass in the specified time, the system will be cancelled the passing rights of this time. The limited time of passing can be set by administrator. |
|
| 5. If pedestrian forgot or read invalid CAD, forbidden to pass and alarm till the pedestrian quit the channel of turnstile. Allow passing after re-read valid card. | |
| 6. In order to meet clients' special requirement and fire safety requirement, the port of communicate interface 485 can be controlled the lifting and falling of rod at long distance. | |
| 7. Prevent rush function, the rod of the gate will be locked when it hasn't got the open signal. | |
| 8. Double anti-pinch function - infrared sensor and machine. | |
| 9. Unified and Standard external electric interface can be connected with various kinds of read and write device,convenient for system integration, and able to accomplished remote control through computer management. | |
| 10. Able to statistics the numbers of pedestrian on passing direction, and show it to the administrator as the manner of LED (optional) | |
| 11. Memory card reader and non-memory card reader,user can be set according to their own needs. | |
| 12. Able to limit the numbers of the inner worker through setting the software, to meet some special requirements in special place. | |
| 13. Operating smoothly, low noise. | |
| Main Application | |
| 1. Apply to control flow of single or bi-directional entrance and exit channel. | |
| 2. The entrance and exit channel of station, pier and tourist attractions. | |
| 3. The ticket checking channel of exhibition, swimming stadium. | |
| 4. Access control of entrance and exit channel of office buildings, hotels, enterprises. | |
| 5. Able to control special channel. | |
