Shenzhen Turnstile Technology Co., Ltd.
High quality, Best service,Reasonable price.
 |
| Place of Origin: | China(mainland) |
| Brand Name: | RS Security |
| Certification: | ISO,FCC,SGS,RoHS,CE |
| Model Number: | RS 996 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 10000USD |
| Packaging Details: | wooden box |
| Delivery Time: | 3-8workdays |
| Payment Terms: | TT |
| Supply Ability: | 3000pcs/month |
| Series: | Half Height Turnstile | Procudt Name: | Half Height Turnstile |
|---|---|---|---|
| Model: | RS 996 | Brand: | RS Security |
| Material: | 304 Stainless Steel | Size: | 1400(L)*280(W)*1000(H)MM |
| High Light: | automatic systems turnstiles,security turnstile gate |
||
Introduction:
The RS 996A is designed to provide unsupervised access control for office or building. The impenetrable contruction eliminates any unauthorized access to restricted areas. To gain authorized passage through the F100, the user must present a valid card for the access control system. Upon presentation of the valid card. the F100 will unlock and allow the user to pass through the direction requested. The turnstile can also work with push button, finger print and face recognition access control system.
Entrance half height turnstile:
Bi-direction
SS304 with good finishing
Interface to access control & reader
Waterproof
Eletrical Entrance Half height turnstile:
Specifications:
1. Power Supply: AC220V±10V ,50Hz / AC110V±10V ,60Hz
2. Power Consumption: 100W/24V
3. Temperature: -15 to 60 degrees
4. Humidity: <95%, without concretion
5. Passage Width: 650mm
6. Passing Speed: 30 persons/min (normal open), 20 persons/min (normal close)
7. Arm Open/Close Time: 2s
8. Input Interface: +12V electrical signal or impulse signal with width more than 100ms, drive current >10mA
9. Communication Interface: RS485 (Distance: <=1200m)
10. Material: 304 stainless steel for body
202 stainless steel for arm
11. Dimension: 1400*1100*1150mm
Arm Length: 600mm
12. Weight: 100kgs
13. Working Environment: Indoors or outdoors with shed
14. Arm Turning: Single direction or Bi-direction
Functions and Features:
1. Problem-self-checking function
2. Many options of working ways: bi-direction card reading; one direction card reading and another no reading; one direction card reading and another freely
3. When power off, arm open automatically and power on again, arm will be held automatically.
4. When valid card read, just push the arm with little force and arm will turn. After passenger passing, arm will be held automatically. Three arms are always closed with each turning 120 degrees.
5. Unique wheeling system is adopted to ensure accurate zero holding and unholding.
6. Standard interface is convenient for connection with different readers and writers.
7. Auto-reposition function: After card read, passenger not pass within regulated time period, full-height turnstile will cancel this passing right. And the regulated time period for passing can be set by managers.
8. Stable running with little noise.
