Shenzhen Turnstile Technology Co., Ltd.
High quality, Best service,Reasonable price.
 |
| Place of Origin: | China(mainland) |
| Brand Name: | RS Security |
| Certification: | ISO,FCC,SGS,RoHS,CE |
| Model Number: | RS 997 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 10000USD |
| Packaging Details: | wooden box |
| Delivery Time: | 3-8workdays |
| Payment Terms: | TT |
| Supply Ability: | 3000pcs/month |
| Series: | Full Height Turnstile | Model: | RS 997 |
|---|---|---|---|
| Brand: | RS Security | Material: | 304 Stainless Steel |
| Size: | 2600L*1350W*2350H Mm | Arm Length: : | 60-70cm |
| High Light: | automatic systems turnstiles,security turnstile gate |
||
Name:Two Channel Auto Full Height Turnstile
Model;RS 997
304 stainless steel high safety full height turnstile barrier gate
1.Brushed
2.304 grade stainless steel
3.RFID access con
4.Run Smooghly
5.size:2600*1350*2200mm
304 stainless steel high safety full height turnstile barrier gate
2. Technical Information:
| Technical date | |
| Material | 304 Stainless Steel |
| Specification | 2600*1350*2200mm |
| Drive motor | DC 24V brush motor |
| The width of the passage | 685mm |
| Pass direction | one or bi-directional |
| Work environment | Indoor or Outdoor |
| Work temperature | -10°C~70°C |
| Relative humidity | ≤90%, no condensation |
| Time of opening/closing | 0.2S |
| Transit speed | 40 People/minute normal open , 25-30 people/minute normal close |
| Reset time after break down | 10s |
| Normal work life | 3000000 times |
| Communication interface | RS485 |
| Input interface | 12V pulse signal with pulse width >100ms, drive current >10mA |
| Main Features&Function | |
| 1.Unique two-way anti-reverse function. | |
| 2. Programmable device's operating status through the built-in small press plate on control board | |
| 3. Anti-rushing function ,when the gate signal is not received, the turnstile arms locked automatically | |
| 4.The center rotor will be set free (default) or locked (optional) automatically when the power is off. 5.Automatic Reset Functions: after you swap the card, during the specific time (the system is 10s). |
|
| 5. Automatic Reset Functions: after you swap the card, during the specific time (the system is 10s). | |
| 6. The turnstile can work with door access control system/ consumption system /ticket system/biometric recognition system/ ESD system and so on. | |
| 7.Can be unidirectional or bidirectional control of personnel access. | |
| 8. Can manager and long-range control the turnstile directly by managing the computer. | |
| Extensible functions: | |
| 1. LED indicator light. | |
| 2. Box house can lengthen, can make custom design | |
| 3.Normally open or closed can be adjust to meet the requirements of the different place. | |
