Pedestrian Fingerprint Waist Height Turnstiles Bevel IR Sensor Gate

Pedestrian Fingerprint Waist Height Turnstiles Bevel IR Sensor Gate

  • Pedestrian Fingerprint Waist Height Turnstiles Bevel IR Sensor Gate
  • Pedestrian Fingerprint Waist Height Turnstiles Bevel IR Sensor Gate
Pedestrian Fingerprint Waist Height Turnstiles Bevel IR Sensor Gate
Product Details:
Place of Origin: China(mainland)
Brand Name: RS Security
Certification: ISO,FCC,SGS,RoHS,CE
Model Number: RS 618
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: 1000USD
Packaging Details: wooden box
Delivery Time: 3-8workdays
Payment Terms: TT
Supply Ability: 3000pcs/month
Contact Now
Detailed Product Description
Series: Tripod Turnstile Product Name: Bevel Tripod Turnstile
Model: RS 318 Brand: RS Security
Material: 304 Stainless Steel Size: 1200*280*980mm
High Light:

automatic systems turnstiles

,

turnstile gate systems





Pedestrian Fingerprint Waist Height Turnstiles Bevel IR Sensor Gate



Specifications

Tripod Turnstile
1. bi-directional, shock-absorber
2. #304 stainless steel
3. IC/ID/barcode control accepted
4. tripod arms

waist height turnstile,tripod turnstile,barrier gate,access control,parking system



Description:


RS Security  is an electro mechanical turnstiles. Its unique mechanical drive design allow the arm to be pushed effortlessly and auto-rotate back without any expensive electric motor.

RS Security can effectively control high volume human traffic ( up to 25 person per minutes ) while still maintaining a welcoming atmosphere. They can easily be integrated with any electronic system for ticketing, access control or time attendance.

RS Security is suitable for indoor. They are optimized economical solution for railway, bus station, factory, colleges, commercial building, library, stadium, game park, bank and etc

Feature:

  • Mechanical drive unit with solenoid locking mechanism eliminate the use of expensive electric motor and reduce maintenance cost.

  • If arm rotated more than half, it will auto-rotate to the next idle position. If arm rotated less than half, it will auto-rotate back to the current idle position.

  • Built in adjustable tensioner to control rotation force to minimize over rotation. Arm just need to be pushed lightly to rotate therefore even elderly or children are able to use the turnstile.

  • Turnstile can be configured to be bi-directional or uni-directional. Housing is locked with special key to avoid tampering.

1. tripod turnstile Functions

1) The tripod turnstile has fully rainproof stainless steel housing, processed by numeric control punching and laser drilling, novel and elegant.

2) The tripod turnstile has unique mounting surfaces (for the installation of card reader and indicator light, etc.), ensuring simple and convenient installation of the turnstile control equipment of system integrators.
3) The interior module of the tripod turnstile has a cushioning device for automatic regulation of hydraulic pressure, which helps to realize low noise, no impact and automatic decelerated returning to home position during operation of the turnstile. The finish of the interior module has been treated by yellow dichromate plating.
4) Programmable turnstile control is available, for one-direction or bi-direction control (to be set by the user).

5) The base cover can be opened using a key, therefore it is convenient for the user to install it. There are card reader supports at both sides of the turnstile, and a 40CM*18CM mounting plate, for the mounting of controller, is fixed at one side of the housing.

6) The tripod turnstile base is fixed with four 10MM expansion bolts.



2. tripod turnstile Technical Parameters and Configuration:





Housing 1200*280*980;
Tripod Bar Length 480 mm, Diameter 40 mm
Power Supply Single-Phase AC220V, 3A, 50/60Hz
Control Voltage DC24V
Electromagnetism No Residual Magnetism, without Magnetization
Buffer Hydraulic Pressure Reset Cushioning, without Bumping Noise
Operating Ambient Temperature Range -10°C~70°C
Operating Ambient Humidity Range 0~95%RH
Net Weight 45kg
Gross Weight 50kg
Power Consumption 40W
