Place of Origin: | China(Mainlan) |
Brand Name: | RS Security |
Certification: | ISO,FCC,SGS,RoHS,CE |
Model Number: | RS 218s |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | 1000USD |
Packaging Details: | Wooden Box |
Delivery Time: | 2-7workdays |
Payment Terms: | TT, |
Supply Ability: | 3000pcs/month |
Series: | Tripod Turnstile | Material: | 304 Or 316 Stainless Steel |
---|---|---|---|
Size: | L520×W480×H980mm | Arm Length: | <550mm (single) |
Pass Ways: | One-way,two-way | Relative Humidity: | <95% |
High Light: | security turnstile gate,turnstile gate systems |
Series:Tripod Turnstile
Product Name:Bi-direction Tripod Turnstile
Model:RS 218S
Material:304 or 316 Stainless Steel
Protection grade: IP54
service: OEM/ODM
direction: Bi-direction
Colors: Bright silver grey and black, or custom
Bi-direction Tripod Turnstile RS 218S is integrated with mechanism, electric and micro-controller and various kinds of identification technologies, compatible with IC, ID, barcode, fingerprint reader and so on to provide intelligent control and management to flow control. Durable, anti-rusty. Provide orderly passage to people, anti-illegal entry or exit, smooth operation, low noise. Arm drops off in condition of emergencies.
Bi-direction Tripod Turnstile RS 218S is widely used in bus station, port, subway, factory, mansion, residential area, hotel, and companies and so on any place that requires a smart flow control.
No.
|
Parameter
|
Value
|
1 |
Material |
304 stainless steel |
2 |
Size |
1200x280x980mm |
3 |
Net weight |
50kg/unit |
4 |
Motor |
24V DC brush |
5 |
Communication interface |
RS485 |
6 |
Transit speed |
30-40 people/minute |
7 |
Close and open time |
0.6S |
8 |
Clear passage width |
550mm |
9 |
Number of led lamp |
1pcs |
10 |
Input voltage |
220V AC220±10% |
11 |
Are length |
510mm |
12 |
Arm diameter |
38mm |
13 |
Cooler fan |
Optional |
14 |
Thermostat |
Optional |
15 |
Service life |
5000,000 times |
16 |
Input interface |
Relay signal, 12V level signal, |
17 |
Work environment |
Indoor and outdoor (shelter) |
18 |
Model |
RS 218S |
1)stamping to the forming with international 304 stainless steel, nice figure, hard and durable,easy to operate, unnecessary to maintain
2)Dimension:1220*280*980 mm
3)Width of Unilateral channel : less than 550(mm)
4)Operating way: automatic,manual
5)Steering direction:one-way, two-way (optional)
6)Operating environment:indoor,outdoor, need awning
7)Passing indicator: eye-catching LED lighting indicator
8)Alarm:no swiping card,with indicating function.
9)Alarm and blocking when swipining-person retrograde(customized)
10)Setting for opening time
11)Setting for whatever longtime for large human traffic
12)Multi-controling function: connecting with walk through metal detector, remote control, barcode technology, IC,ID ,other controling device etc.
13)Remote controling by connecting with RS485 card or TCP-RS485 in computer
Automatically reset blocking when no passing within setting time
14)Setting limited quantity of passing through (customized)
15)Statistic quantity of passing through (customized)
Application :
Stations, quay,senic spots, import and export channels, exhibition, swimming pool ,other tickets channel,etc.
1.Q:Can I know the difference between automatic type and manual type?
A:First, for manual type, it doesn't have electric control device. For automatic type, it can be compatible with card, finger print,barcode etc. Second, for manual type, it is single direction.
2.Q:Do you have any MOQ limit for tripod turnstile?
A:No, we don't have MOQ limit for tripod turnstile.
3.Q:What is the lead time for tripod turnstile?
A:For 10 units, we need 5-7 working days. For 20-50 units, we need 15 working days. For 100 units, we need 25 working days.
4.Q:Can I buy the mechanim of tripod turnstile?
A:yes, if you need, we can offer you.
5.Q:Do you offer guarantee for the products?
A:Yes, we offer one year warranty for the whole unit product and the accessories.
6.Q:Is OEM,ODM available?
A:Yes, it is available.
7.Q:Does the price include card reader and access control?
A:No. If you need, we can offer you the price.
