Anti Rusted Light Steel Villa Fire Resistance Prefabricated Cottages Granny Unit

Anti Rusted Light Steel Villa Fire Resistance Prefabricated Cottages Granny Unit

  • Anti Rusted Light Steel Villa Fire Resistance Prefabricated Cottages Granny Unit
  • Anti Rusted Light Steel Villa Fire Resistance Prefabricated Cottages Granny Unit
Anti Rusted Light Steel Villa Fire Resistance Prefabricated Cottages Granny Unit
Product Details:
Place of Origin: Yangzhou,Jiangsu,China
Model Number: Custom-made
Payment & Shipping Terms:
Minimum Order Quantity: 4 units
Price: negotiable
Packaging Details: Empty sea freight container
Delivery Time: 1 month
Payment Terms: T/T or LC
Supply Ability: 200 units per month
Contact Now
Detailed Product Description
Material: Steel Lifetime: More Than 10 Years
Wind-proof: Maximum 60 Meters Per Second Fire Resistance: All The Materials Used Will Be Fire Resistance
Snow Resistance: Maximum 2.9KN/M2 As Required Water And Heat Insulation: 100 Mm In Thickness Can Match More Than 1m Thickness Of Brick Wall
High Light:

prefabricated cottages

,

prefabricated housing modules



Anti Rusted Steel Strucuture Prefabricated Cottages Waterproof Resistance





Description



The container house is movable as a whole unity. This kind of container house is reusable

usually as offices in domestic areas other than as habitable houses. Using a kind of modulus

design, with security nets, doors and floor, it‘s firm and safe. Cabinet unit structure for the

introduction of steel and cold-formed steel welded together to make up standard components.

The container house can be designed just as just one unit or connected to a whole from several

boxes, by simple connection such as bolts.





Application



Carport, Hotel, House, Kiosk, Booth, Office, Sentry Box, Guard House, Shop, Toilet, Villa, Warehouse, Workshop, Plant, kitchen, corridor.





Specification



(I)

PRIMARY STRUCTURE

LIGHT STEEL KEEL

WALL SYSTEM:140/89MM; ROOF SYSTEM: 70MM(Q550 GALVANIZED)



Light gauge steel channel

(II)

MAINTENANCE

EXTERNAL WALL

27mmPU EMBOSSED STEEL PANEL+HOUSE WRAP+12mmOSB BOARD+150mm INSULATION GLASS WOOL+12mm WATERPROOF GYPSUM BOARD

INTERNAL WALL

12mm WATERPROOF GYPSUM BOARD+150mm INSULATION GLASS WOOL

FALSE CEILING

0.5mm COLOR STEEL SHEET

9mm GYPSM BOARD

FLOOR SUPPORTING BOARD

1mm GALVANIZED MODELED FLOOR SUPPORTING BOARD

GALVANIZE

FLASHING EDGING

0.5mm SELF FOLDING COLOR STEEL SHEET

DOOR

1200*200mm STEEL DOOR

960*2050mm STEEL DOOR

800*210mm PVC MODELED DOOR

700*210mm PVC MODELED DOOR



Sample of the wall system

(III)

FITTINGS

HARDWARE



RAINWATER SYSTEM

75*50mmPVC RECTANGULAR TUBLE

PVC EAVES GUTTER(WITH ACCESSORIES)

ELECTRICITY

LIGHTS, SWITCHES, SOCKETS, DISTRIBUTION BOX





Competitive Advantage

  1. Easy to install ---- all the fixed holes and pipe holes are prepunched,2-3 workers can finish the installation.(save 70% labor cost, shorten 10% construction period, fasten 30% the construction process)
  2. Fire and insect resistance ----- All the keels are galvanized, no need to use pesticide, preservative or glue. The wall system is filled with anti-fire glass wool and the steel itself is anti-fire.
  3. Prefabricated ------ our factory will first manufacture all the keels and then prefabricate the walls and last pack them.
  4. Heat insulation ------ the steel wall system is not affected by the temperature or humidity so that the more heat and air conditioner utility kept in the house, the more energy will be saved.
  5. Wind &seismic resistance ----- the firm connection and the hardness of the steel itself can against the seismic and hurricane to a large extend.
  6. Steel’s high tenacity make it the best building material to resist the seismic.
  7. Artistic and comfortable ----- the inner decoration is as per your wish. And the air quality is good.
  8. Energy conservation and environment protection------only 1% construction wastes. The recycling rate of the steel reaches 70%. What’s more, until the house life is over, the steel can still be used.

Anti Rusted Light Steel Villa Fire Resistance Prefabricated Cottages Granny Unit 0
