Powder Coating Telescopic Sliding Gate Automatic Cantilever Sliding Gates

Powder Coating Telescopic Sliding Gate Automatic Cantilever Sliding Gates

  • Powder Coating Telescopic Sliding Gate Automatic Cantilever Sliding Gates
Powder Coating Telescopic Sliding Gate Automatic Cantilever Sliding Gates
Product Details:
Place of Origin: China
Brand Name: Hongmen
Certification: CE
Model Number: P863B-G
Payment & Shipping Terms:
Minimum Order Quantity: L=3m * H=1.5m
Packaging Details: Iron rack plus plywood
Delivery Time: 10 Working Days
Payment Terms: T/T
Supply Ability: 30.00m/month
Contact Now
Detailed Product Description
Material: Industrial Grade Aluminium Alloy Colour: Grey / Black / Silver / White / Others
Surface Treatment: Powder Coated Motor: 500W
Voltage: 220VAC (DC Available) Operation: Telescopic Sliding
Length: Up To 30m Height: Up To 2.0m
Highlight:

Automated Sliding Gates

Powder Coating Telescopic Sliding Gate Automatic Cantilever Sliding Gates

P863B-G


Features:

     1.CE Certified.
     2.EMO Button (Emergency Stop Button).
     3.Trackless Operation.
     4.Industrial Grade Aluminium Alloy (6063-T5).
     5.Wireless Remote Control (433MHz).
     6.Powder Coating
     7.Dispatch In Modules Form (Transportation Friendly).
     8.Smart Power Outage Clutch.
     9.Anti- Collision IR Sensor.
     10.Anti- Climb Photo Cell.

Specifications:
Powder Coating Telescopic Sliding Gate Automatic Cantilever Sliding Gates 0

Material Specification:

Description Material Hardness (HW) Specification (mm)
Upper Beam 6005-T5 13-17 115*80*d3
Lower Beam 6003-T5 10-17 135*80*d3-4
Front Gate Frame A/ Rear Gate Frame 6003-T5 10-13 110*80*d2.0
Front Gate Frame B 6003-T5 10-13 80*80*d2.5
Cross Tube 6003-T5 10-13 35*29*d1.0
Auxillary Gate Frame 6003-T5 10-13 70*25*d1.0
Supportive Bar SUS304 10-13 42*44*d2.0
Front/Rear Upright Post 6003-T5 10-13 180*100*d3.0
Rail 6003-T5 10-13 25*18



Technical Specification:

Operation Voltage 220V± 10%, 50Hz-60Hz
Operation Temperature -25ºC to +70ºC
Environment Humidity < 90%
Operation Speed 18m/min
Motor Power Rating 500W
Motor RPM 1400r/min
IP Rating IP54
Insulation Grade F
Speed Reduction Ratio 30: 1
Remote Distance 50m (empty space)



Q: How do you ship it out to worldwide customers?

A: We take all necessary precaution before its dispatch from the factory. The most inner layer is wrapping up with a thin layer of shrink wrap, then follow by a customized EPE form to firmly secure its position within the carton box.



Q: Do you take any additional precaution if we only purchase a few sets whereby we going to ship it via LCL?

A: Yes, we will place 4 sets of the well-packed crowd control barriers on upright position and sitting firmly on top of a plywood pallet.



Q: Do you go through the fumigation process before exporting the goods?

A: Due to the facts that all packaging are non-timber material, and same goes to the pallet is made of plywood which we don’t have to worry about fumigation certifications



Q: Do you have any export experience?

A: Yes, our company have more than 16 years of experience of exporting such innovative and unique products to all over the world


Powder Coating Telescopic Sliding Gate Automatic Cantilever Sliding Gates 1
