Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment

Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment

    • Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment
    • Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment
  • Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment

    Product Details:

    Place of Origin: China(mainland)
    Brand Name: RS Security
    Certification: ISO,FCC,SGS,RoHS,CE
    Model Number: RS1009

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: 2000USD
    Packaging Details: wooden box
    Delivery Time: 3-8workdays
    Payment Terms: TT
    Supply Ability: 3000pcs/month
    Contact Now
    Detailed Product Description
    Material: 304 Stainless Steel Size: 1200*165*990mm
    Color: Gray And Black Product Name: Pedestrian Wheelchair Drop Arm Turnstile
    Lane Width: 600-1200mm Processing Way: OEM/ODM(Optional)
    High Light:

    security barriers and gates

    ,

    biometric access control system





    Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment





    Quick Detail:



    Brand Name:  RS Security

    Product Name:Pedestrian Wheelchair Drop Arm turnstile

    Lane width: 600-1200mm

    Application: Office building, Bank,

    Material: 304 stainless steel

    Size: 1200x165x990mm

    Processing way:OEM/ODM(Optional)





    Description:



    • The barrier arm turnstile is a perfect combination of aesthetic look and fast passage.
    • Normal close or normal open can be switched.
    • It provides standard or wide lane to meet different requirements for the lane width, the lane width can be 600-1200mm



    Features



    • Bidirectional control, by authorized card or biometric identifications, push button and so on
    • Can be integrated with all kinds of access control systems,
    • Flow direction guide with high bright led lamp
    • Anti-punch, the barrier will not close if it detects people inside the passageway
    • Anti-tailgating, it allows only one person to pass for an authorized card presented.
    • Anti-panic, when power off, the barrier will open for people to go through.
    • Normal close or normal open (for group pass)
    • Close and open by remote control
    • Card reading memory function, the user can set multiple time card reading passing or single time card reading passing
    • Failure detection and alarm functions;



    Optional features

    Counter:

    Voice speech

    Remote control

    Applications:

    Office building, factory, fitness club, prison, hotel lobby, school, port, exhibition hall.



    Traffic type



    Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment 0Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment 1Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment 2Remote Control Arm Barrier Gate , Wheelchair Entrance Managerment 3



    Specification



    Material

    304 stainless steel

    Input voltage

    220V AC220±10%

    Size

    1200x165x990mm

    Arm length

    300-600mm

    Net weight

    102kg/unit

    Clear passageway

    600-1200mm

    Motor

    24V DC brush

    Top Cover

    Acrylic or stainless steel

    Communication interface

    RS485

    Sensor beams

    5 pairs for 1 complete lane

    Transit speed

    30-40 people/minute

    Service life

    3000,000 times

    Close and open time

    0.6S

    Input interface

    Relay signal, 12V level signal,

    Clear passage width

    600mm-1200mm

    Work environment

    Indoor and outdoor (shelter)

    Number of led lamp

    3pcs

    Model

    RS1008b





    Competitive Advantage:



    Our advantage:

    • We are a leading manufacturer of turnstile and speed gate in China.
    • We focus on pedestrian turnstile gates.
    • We keep stock for regular products and we can support small orders. Usually, our lead time is just 3 days.
    • Design products according to customers’ requirements.
    • Credibility: We are SGS certificated Supplier. Our customers are located over 50 countries
    • Gratitude: We cherish the business chance you give us and return you with quality products and good service.
    • Professional: We have been in this business for more than 8 years. We have a strong professional team with various experiences.
    • We keep doing new product development. Our goal is to enhance our competitive capacity constantly.
    • Price: very competitive price and good quality products
    • Quality: we do 100% inspection before the shipment.
    • Promise: we are always ready to take the responsibility if any loss caused to our customer due to our mistakes.
    •
