Automatic drop arm barrier

Automatic drop arm barrier

    • Automatic drop arm barrier
    • Automatic drop arm barrier
  • Automatic drop arm barrier

    Product Details:

    Place of Origin: China
    Brand Name: TDZ
    Certification: CE
    Model Number: TDZ-E601

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: USD 500 -1000 / Piece
    Packaging Details: paper carton and wooden cases
    Delivery Time: 3-4 working days
    Payment Terms: T/T, Western Union, MoneyGram, L/C, D/A, D/P
    Supply Ability: 200 pieces / month
    Contact Now
    Detailed Product Description
    Material: 304 / 316 Stainless Steel Thickness: 1.5mm
    Dimension: 600*160*1000mm Package Size: 650*210*1050mm
    Occasions: Bank,government,railway,airport Channel Width: 600 -900 Mm
    Machine Core: Fully Automatic Motor: Brushless DC Motor (24V)
    Power Supply: AC 220 ± 10%V,50Hz Normal Life: 3,000,000 Times
    Temperature: -10℃ - 50℃ Work Environment: Indoor And Outdoor
    MOQ: 1 Piece Package: Paper Carton And Wooden Case
    Leading Time: 4 - 5 Working Days For Sample Production Payment Terms: T/T Or West Union
    Model: TDZ-E601

    Intelligent Automatic drop arm barrier Fingerprint Turnstile outdoor

    Quick Details

    • 316 stainless steel automatic drop arm barrier with card reader
    • Channel width:600-900mm
    • 3 pairs of infrared sensor
    • Control panel with counting function,LED display function (optional).
    • Can use with RFID,Mifare,fingerprint,bar code,facial scanner,etc access control products

    Product Descriptions:

    1. Waterproof, sunscreen, anti-temperature, anti-cold.​​
    2. Access Prompt function:Red and green light prompt the passing information.
    3. Can set a one-way or two-way control
    4. Compatible IC, ID, magnetic card, bar code card, and other control equipment.
    5. Small button into the main control panel ,can be set state of equipment.
    6. Anti-pinch, anti bumps function
    7.  Scour protection function ,when the gate signal is not received, arms keep closed
    8. With automatic reset function,if does not pass in the set time,turnstile will get back
    9. Normally open or closed can be freely adjusted
    10. can be used with a variety of reading devices, work when it receive relay switch signal
    11. Fire emergency function,after power,arms will be automaticlly opened.When on power,will be closed automatically




    Technical Parameters


    Material 304/316 stainless seel (optional)
    Fishing Brushed surface (standard) / Polishing surface
    Dimension 600*160*1000mm
    Channel width 600 - 900mm
    Drive motor Brushless DC motor (24V)
    Power supply AC220 (110) ± 10%V,50Hz
    Working life 3,000,000 times
    Communication Interface RS485 / RS232,Ethernet
    Transit Speed 30 - 40  passage / minute
    Work Environment Indoor / Outdoor (Shelter)
    Use Place Station,park,apartment,school,factory,bank,building


    Customized Features:


    1. Alternative Materials, Finishes and Custom Design
    2. Access Control System Integration
    3. Ticket System Integration
    4. Camera System Integration
    5. Thermostat System Integration
    6. Remote-Controlled Button
    7. Usage Counters
    8. Waterproof and Dustproof Design: IP53 for mechanical module, IP65 for electric module
    9. SDK and technical support will be provided for Secondary development of software
