Bi-Directional Wide Lane Flap Barrier Gate With IR Sensor And Anti-pinic



Bi-Directional Wide Lane Flap Barrier Gate With IR Sensor And Anti-pinic





Quick Detail:



product name : flap gate turnstle



Brand Name:       RS Security



Model Number:   RS 888F



Application: custom, port, airport,



 Material:     304 stainless steel



Size:      1400x300x990mm



Bi-directional access control



Access control turnstile , flap barrier,time attendance,traffic barrier, tripod turnstile, security turnstile, full height turnstile, speed gate, swing barrier



Flap Barrier Description:



• The double flap gate is designed for places that requires wide passage access control, it



is for wheelchair or big luggage , the max lane width up to 900mm.



• The speed gate barriers are designed to work in a normally closed mode and retract



inside the pedestal after a valid card has been presented to allow the authorized user to



pass. The fast moving close behind the authorized person to deter tailgaters.







Flap Turnstile Features



1.Unique incomplete wheel transmission is adopted to make flap barriers held or unheld in zero



position more accurate and reliable.


2.Running stable, little noise and no mechanical impact


3.Self-checking-power-on function, if power on, flap barrier will auto get to be held.


4.Flap barrier will auto alarm when some unauthoried person gets in.


5.Various working means can be set in the control panel menu, namely: bi-direction card reading



passing, or one direction card reading passing and another passing limits, or one direction card



reading passing and another free passing, etc.


6.If power off, arm will open automatically while power on late.


7.It is with RS485 connection for far control arm up and down to satisfy the special needs or fire



control requirements.


8.It is with standard electrical interface to connect various kinds of readers and writers for easy



integration and also computer far control and management can be realized by computer.


9.Passing direction will be shown by LED and passengers will know which direction is allowed to



pass.


10.Re-position function. After card reading, if passenger not through within the specific time, system



will auto cancel passing right for this time and the limit passing time length can be set.


11. Optional:


1) Counter and counter display


2) Access controller or card reader


3) Key by-pass







Applications:





High security places, factory, fitness club, prison, hotel lobby, school, port, exhibition hall.







Traffic type









Specification



Material	304 stainless steel	Input voltage	220V AC220±10%
Size	1400x300x990mm	Arm width	2750m
Net weight	72kg/unit	Arm material	Acrylic or soft arm
Motor	24V DC brush	Top Cover	Acrylic or stainless steel
Communication   interface	RS485	Sensor beams	5 pairs for 1 complete lane
Transit speed	30-40 people/minute	Service life	5000,000 times
Close and open time	0.6S	Input interface	Relay signal, 12V level   signal,
Clear passage width	600mm	Work environment	Indoor and outdoor   (shelter)
Number of led lamp	3 pcs	Model	RS 888F





Competitive Advantage:





• We are a leading manufacturer of turnstile and speed gate in China.



• We focus on pedestrian turnstile gates.



• We keep stock for regular products and we can support small orders. Usually, our lead



time is just 3 days.



• Design products according to customers’ requirements.



• Credibility: We are SGS certificated Supplier. Our customers are located over 50



countries.



       Gratitude: We cherish the business chance you give us and return you with quality products and



good service.



       Professional: We have been in this business for more than 8 years. We have a strong



professional team with various experiences.



       We keep doing new product development. Our goal is to enhance our competitive capacity



constantly.



       Price: very competitive price and good quality products.



       Quality: we do 100% inspection before the shipment.



       Promise: we are always ready to take the responsibility if any loss caused to our customer due



to our mistakes.
