Shenzhen Turnstile Technology Co., Ltd.
High quality, Best service,Reasonable price.
 |
| Place of Origin: | China |
| Brand Name: | WONSUN |
| Certification: | CE, ISO, SGS |
| Model Number: | WSTP-152 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in bubble wrap firstly, and then reinforced with carton for outer packing. |
| Delivery Time: | 3-7 working days after received your payment |
| Payment Terms: | T/T,Western Union,Money Gram,Alibaba Trade Assurance,Paypal etc., |
| Supply Ability: | 1000 Sets/Month |
| Name: | Automatic Inductive Detector Sliding Gate Motor Accessories Wireless Loop Detector | Voltage: | 220V/110V/24V/12V |
|---|---|---|---|
| Power Consumption: | 4.5VA | Output Relays: | 240V/5A |
| Operating Temperature: | -20°C To +70°C | Frequency Range: | 20 KHz To 170 KHz |
| High Light: | Security Barrier Gate,Automatic Flap Gate |
||
Automatic Inductive Detector Sliding Gate Motor Accessories Wireless Loop Detector
Application Scope
Parking lot entrances vehicle detection
Parking lot space information acquisition system
Electronic police traffic lights snap shot system
Traffic monitoring system
Main Features
♦ Industrial engineering design concept
♦ Standard industrial guide installation
♦ Strong anti-jamming ability and stability
♦ Variety of output interface adapted to different scene
♦ Variety of shape choice meet differentiation demand
♦ High temperature stability
♦ Environment drift automatic compensation function
♦ Coil automatic fault detection function
♦ When the DIP switch is on position or changing the presence output time, Self-detection would be done
♦ ABS align to the pillar which can combine with each other compactly
♦ Presence output time can be adjustable
♦ Work mode can be set by the DIP switch
♦ Pulse output or permanent output can be adjustable
Technical Data
| Supply voltage AC | 220V, 110V, 24V, 12V |
| Supply voltage DC | 24V, 12V |
| Sensitivity | 0.013%-0.1% |
| Operating Temperature | -20°C to +70°C |
| Storage temperature | -40°C to +85°C |
| Frequency Range | 20 kHz to 200 kHz |
| Reaction Time | 100ms |
| Loop inductance | Ideal: 80μH to 300μH (incl. conn. wiring) |
| Loop connection | <5m optimal |
| Loop connection wiring | Maximum length 200 meters Twisted at least 20 times per meter |
| Dimensions | 37x74x85 mm (WxHxL) |
| Net Weight | 250g |
