Shenzhen Turnstile Technology Co., Ltd.
High quality, Best service,Reasonable price.
 |
| Place of Origin: | China |
| Brand Name: | WONSUN |
| Certification: | CE, ISO, SGS |
| Model Number: | WSTP-158 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in bubble wrap firstly, and then reinforced with carton for outer packing. |
| Delivery Time: | 3-7 working days after received your payment |
| Payment Terms: | T/T,Western Union,Money Gram,Alibaba Trade Assurance,Paypal etc., |
| Supply Ability: | 1000 Sets/Month |
| Name: | High Quality Sliding Gate Motor Accessories Infrared Photocell Beam Sensors | Powe Supply: | DC 10.5V~24V/0.5A |
|---|---|---|---|
| Infrared Wave Length: | 940mm | Response Spee: | 50ms |
| Infrared Transmission Frequency: | 1.92KHZ | Warranty: | 1 Year |
| High Light: | Security Barrier Gate,Automatic Flap Gate |
||
Waterproof Sliding Gate Motor Accessories Infrared Photocell Beam Sensors
| Specification for Infrared Photocell Beam Sensors For Barrier Gate | |
| Model | WSLP23-7 |
| Working voltage | DC 12 - 24V |
| Working current | R - 15mA ; T - 30mA |
| Installation | Outdoor |
| Use | Home Security/Access Control System |
| Certificate | CE certificated |
| Detecting distance | 15m |
| Frequency | 1.92KHz |
| Wave length | 940nm |
| Working temperature | -25℃~+55℃ |
| Alarm Output | NC/NO |
| Relay output | 1A max 36V |
| Waterproof grade | IP55 |
| Dimension | 49.2*75.3*29.6mm |
Features:
1.Single beam sensor/single beam detector is used for automatic slide door, coil door , garage door windows etc.
2.Consists of a transmitter and a receiver, and the integrated amplifier can produce infrared beam.
Narrow infrared beam (I or II) can avoid interruption by external light.
3.Even installed at low height(20-40cm from the floor), the detecting distance can also be guaranteed(5-15meters).
4.The beam produced by MICROCELL provides a self-detecting function for the sliding doors. Once the self-detecting beam is interrupted, the door will stop closing and reverse rapidly to the utmost width. The door will open until the detecting beam is resumed. When the door completely closes, the detecting beam becomes invalid.
