Shenzhen Turnstile Technology Co., Ltd.
High quality, Best service,Reasonable price.
 |
| Place of Origin: | China(Mainlan) |
| Brand Name: | RS Security |
| Certification: | ISO,FCC,SGS,RoHS,CE |
| Model Number: | RS 1008 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 2000usd |
| Packaging Details: | Wooden Box |
| Delivery Time: | 2-7workdays |
| Payment Terms: | TT, |
| Supply Ability: | 3000pcs/month |
| Material: | 304 Stainless Steel | Color: | Black |
|---|---|---|---|
| Model: | RS 1008 | Size: | 1200*165*980mm |
| Weight: | 80KG | Motor Voltage: | 220V |
| High Light: | security turnstile gate,turnstile gate systems |
||
Product Name:Drop Arm Turnstile
Model:RS 1008
1.Single Pole Barrier Gate
2.Bi-direction pass
3.Arms auto drop when power off
4.Traffic light indicator
5.RFID interface
Low Noise,Run Smoothly Anti-Shock
Automatic Stainless Steel Drop Arm Barrier Gate ; drop arm gate,tripod turnstile,turnstiles,access control,time attendance,parking system,traffic barrier,security gate
Applications:
Drop Arm turnstiles are mainly used in parks, subway, customers, airport, bus station,
office building, scenic spot, community, attractions, and exhibition hall doors, residential,
Construction Sites, Industrial Plants, Marquee Golf Tournaments, State Fairs, Special
Sporting Events and Festivals!
|
Parameter
|
Value
|
Parameter
|
Value
|
| Name | Different Arm Size For Single Pole Barrier Gate | Model | RS 1008 |
| Housing Size | 1200L*165W*980H(MM) | Passing speed | 30 person/min |
| Housing Material | 202or304 grade stainless steel optional | Working Voltage | AC220V±10V, 50HZ |
| Net Weight | 90KG | Motor voltage | 220V |
| Gross Weight | 100KG | Rated Power | 80W |
| Control type | IC/ID/Barcode control accepted |
Transmission | Sine Linkage |
| Boom length | ≤700mm | Frequency | 50~60Hz |
| Logic voltage | 24v | Working temperature | -30°C--+70°C |
| Working mode | one directional or bi-directional optional |
Operating humidity | ≤90% non-condensing |
| Communication Interface | RS485/RS232 | Operation life | ≥5 million times |
1. Unique incomplete wheel transmission is adopted to make turnstiles held or unheld
in zero position more accurate and reliable.
2. Running stable, little noise and no mechanical impact
3. Self-checking-power-on function, if power on, turnstile will auto get to be held.
4. Various working means can be set in the control panel menu,
5. If power off, arm will fall automatically while power on later, arm should be lift by hand.
First press the arm with a little force and then lift it manually.
5. RS485 connection for far control arm up and down to satisfy the special needs or
fire control requirements.
7. It is with standard electrical interface to connect various kinds of readers and writers
for easy integration and also
computer far control and management can be realized by computer.
8. It will count the pedestrian and will show the number on LED display directly.
(LED is optional)
9. LED direction guide
10. Card reading memory or card reading without memory function can be set.
11. If working with software, the total-in-population can be set to satisfy special
12. Re-position function.
13. Card mounting is available.
14. Uncompleted wheel turning system is adopted for locking the turnstile in zero,
and unlocking will be more reliable and accurate.
15. Extend:
1), Voice prompt
2), dual color, 4 words LED display
3), fingerprint card
4), spit vote
5), remote mode
16, Audio prompt function is optional.
17, Effective railing barrier opening signal with memory and without memory
can be set (adjustable).
