Luxury Waterproof Smart Full Height Turnstile Suitable For Intelligent

Luxury Waterproof Smart Full Height Turnstile Suitable For Intelligent

    • Luxury Waterproof Smart Full Height Turnstile Suitable For Intelligent
    • Luxury Waterproof Smart Full Height Turnstile Suitable For Intelligent
  • Luxury Waterproof Smart Full Height Turnstile Suitable For Intelligent

    Product Details:

    Place of Origin: China(mainland)
    Brand Name: RS Security
    Certification: ISO,FCC,SGS,RoHS,CE
    Model Number: RS 997

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: 13000usd
    Packaging Details: wooden box
    Delivery Time: 3-8workdays
    Payment Terms: TT
    Supply Ability: 3000pcs/month
    Contact Now
    Detailed Product Description
    Series: Full Height Turnstile Product Name: Dual Access Full Height Turnstile
    Modal: RS 997 Brand: RS Security
    Material: 304 Stainless Steel Size: 1400*2760*2300mm
    High Light:

    automatic systems turnstiles


    security turnstile gate


    Luxury Waterproof Smart Full Height Turnstile Suitable For Intelligent

    1. Name:Double Passages Full Height Turnstile
    2. Model:RS 997
    3. RS Security  brandnew electronical locks;
    4. use world's advanced tech smart passage turnstile
    5. intelligent gate barrier
    6. Waterproof,high security

    Benefits & Features

    • bi-directional passage
    • electrical controls for both directions
    • integration with any identification or access control system
    • automatic reset of barrier wings after each passage
    • push button switch override controls for emergency situations
    • cable or wireless remote control
    • indoor and outdoor application
    • high level of security
    • anti-backup device to prevent reverse rotation

    1. Rainproof housing, anti-corrosion coating iron or #304 stainless steel
    2. CNC stamping and laser drilling, presenting a novel and elegant appearance
    3. Innovative and unique mounting surface ensures simple and convenient installation for system integrators;
    4. Direction can be set as single-direction or bi-direction
    5. Direction indicator
    6. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc. (Access controller needed)
    7. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically;
    8. When power failure, lane will be free to pass, complying with fire safety requirements.
    9. The mechanism is equipped with an automatic regulated hydraulic buffer device. There is no noise and impact when running.
    10. Dual-bearing device, keeping the gate in balance when there is external force.

    Technical Data :
    Voltage : AC220V,50HZ
    Control circuit : DC24V
    Power consumption : 100W
    Signal output: relay or 12v pulse
    Material : 304 stainless steel
    S/S thickness : 1.0~1.5mm
    Surrounding Temp : -25~+70
    Hydraulic damper : adjustable
    Dimension : 2600x1438x2310mm
    Humidity : 95%
    Protection level : IP55
    Entry passage width : 650mm

    1Product namefull height turnstiles
    2Model ItemRS 997
    3VoltageAC 220V/110V±10%
    6Control circuit:DC24V
    7Power consumption40W
    8Working temperature-20°C~60°C
    9Working humidity0~95%RH
    10Maximum bearing capacity80kgs
    11Bar length600mm

    Product Descriptions
    Three-arm full height turnstile: Oblong top cover; single passageway, detachable;  easy to transport.
     The housing is made of high quality stainless steel, and all the internal parts are with antirust and antiseptic treatment, therefore, the turnstile is durable. The whole machine works stably, mute, with low power consumption, energy conservation and environment protection.
    With fully-auto structure; after turnstile receives legal signal, the arms will rotate forward a certain angle to remind people to pass; after pushing forward the arm, the arms will start to slowly rotate at 120°to finish one passing action; turnstile works stably, safely, and reliably, And the turnstile is with various intelligent alarm signals.
    With large hinder area can achieve one time to pass one person effectively, and it's suitable to be used at the smaller visitor flow rate and high security required occasions.
    At the low-temperature environment, can be customized to install the constant temperature systems in the turnstile according to the requirement of customers.
     Provide the control software for human-machine interface and SDK protocol freely. It can achieve batch control and debugging function conveniently and the expansibility is very strong.
    Luxury Waterproof Smart Full Height Turnstile Suitable For Intelligent 0
