Place of Origin: | China(mainland) |
Brand Name: | RS Security |
Certification: | ISO,FCC,SGS,RoHS,CE |
Model Number: | RS 997 |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | 13000usd |
Packaging Details: | wooden box |
Delivery Time: | 3-8workdays |
Payment Terms: | TT |
Supply Ability: | 3000pcs/month |
Series: | Full Height Turnstile | Product Name: | Dual Access Full Height Turnstile |
---|---|---|---|
Modal: | RS 997 | Brand: | RS Security |
Material: | 304 Stainless Steel | Size: | 1400*2760*2300mm |
High Light: | automatic systems turnstiles,security turnstile gate |
Luxury Waterproof Smart Full Height Turnstile Suitable For Intelligent
Description
Benefits & Features
1. Rainproof housing, anti-corrosion coating iron or #304 stainless steel
2. CNC stamping and laser drilling, presenting a novel and elegant appearance
3. Innovative and unique mounting surface ensures simple and convenient installation for system integrators;
4. Direction can be set as single-direction or bi-direction
5. Direction indicator
6. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc. (Access controller needed)
7. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically;
8. When power failure, lane will be free to pass, complying with fire safety requirements.
9. The mechanism is equipped with an automatic regulated hydraulic buffer device. There is no noise and impact when running.
10. Dual-bearing device, keeping the gate in balance when there is external force.
Technical Data :
Voltage : AC220V,50HZ
Control circuit : DC24V
Power consumption : 100W
Signal output: relay or 12v pulse
Material : 304 stainless steel
S/S thickness : 1.0~1.5mm
Surrounding Temp : -25~+70
Hydraulic damper : adjustable
Dimension : 2600x1438x2310mm
Humidity : 95%
Protection level : IP55
Entry passage width : 650mm
1 | Product name | full height turnstiles |
2 | Model Item | RS 997 |
3 | Voltage | AC 220V/110V±10% |
4 | Frequency | 50/60Hz |
5 | Current | 3A |
6 | Control circuit: | DC24V |
7 | Power consumption | 40W |
8 | Working temperature | -20°C~60°C |
9 | Working humidity | 0~95%RH |
10 | Maximum bearing capacity | 80kgs |
11 | Bar length | 600mm |
Product Descriptions
Three-arm full height turnstile: Oblong top cover; single passageway, detachable; easy to transport.
The housing is made of high quality stainless steel, and all the internal parts are with antirust and antiseptic treatment, therefore, the turnstile is durable. The whole machine works stably, mute, with low power consumption, energy conservation and environment protection.
With fully-auto structure; after turnstile receives legal signal, the arms will rotate forward a certain angle to remind people to pass; after pushing forward the arm, the arms will start to slowly rotate at 120°to finish one passing action; turnstile works stably, safely, and reliably, And the turnstile is with various intelligent alarm signals.
With large hinder area can achieve one time to pass one person effectively, and it's suitable to be used at the smaller visitor flow rate and high security required occasions.
At the low-temperature environment, can be customized to install the constant temperature systems in the turnstile according to the requirement of customers.
Provide the control software for human-machine interface and SDK protocol freely. It can achieve batch control and debugging function conveniently and the expansibility is very strong.
