Place of Origin: | China(mainland) |
Brand Name: | RS Security |
Certification: | ISO,FCC,SGS,RoHS,CE |
Model Number: | RS 998 |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | 13000usd |
Packaging Details: | wooden box |
Delivery Time: | 3-8workdays |
Payment Terms: | TT |
Supply Ability: | 3000pcs/month |
Series: | Half Height Turnstile | Product Name: | Half Height Turnstile |
---|---|---|---|
Model: | RS 998 | Brand: | RS Security |
Material: | 304 Stainless Steel | Size: | 1400(L)*280(W)*1000(H)MM |
High Light: | automatic systems turnstiles,security turnstile gate |
Product Description
Security access control system three lanes automatic full height turnstile
This turnstile is known for its attractive stainless steel housing, ergonomically shaped for an optimised flow of visitors. It is available with 3 or 4 rows of crossbars to control unsupervised areas.
Basic Description:
The full height turnstile is designed with unique, strong, and durable mechanical to provide unsupervised access control for office or building which realize intelligent pedestrian control and management. .The impenetrable construction eliminates any un-authorized access to restricted areas. To gain authorized passage through the turnstile, the user must present a valid card for the access control system. Upon presentation of the valid card. The turnstile will unlock and allow the user to pass through the direction requested. And the turnstile can also work with push button, fingerprint and face recognition access control system.
This full-height turnstiles designs with tailored stainless steel make its elegance-looking,durable and anti-oxidation .Considering unique requests, we built-in standard electrical interface to best-fit customer easier using magnetic card, barcode, RFID cards integrated .This system provides civilized, well-organized pass management .
Considering Fire emergency happen, the system built-in unique fire-control interface, turnstile will be in free enter/exit working mode when power off.
Technical parameters
Framework material:304/316 stainless steel
Dimension:L1500*W1400*H1100(mm)
Standard length of pole: 500mm
Standard passage width: 600mm
Working voltage: AC220 ±10% V/50 ±10% HZ AC110V±10%/ 50Hz±10%
Driving electromotor: DC 20W/24V
Communication interface: RS485 standard (distance less than 1200metres)
Input interface: Dry contact signal or 12V signal or DC12V
Driving current: > 10mA
Normal life-span: 3million times
Transit speed: 30-50 persons/min
Working environment: indoor, outdoor( with a tent over)
Working temperature: -10°C— 50°C Relative humidity: ≤90% no condensation
1 | Model | RS 998 |
2 | Voltage | AC 220V/110V± 10% |
3 | Frequency | 50/60Hz |
4 | Current | 3A |
5 | Control circuit: | DC24V |
6 | Power consumption | 40W |
7 | Working temperature | -20° C~60° C |
8 | Working humidity | 0~95%RH |
9 | Maximum bearing capacity | 80kgs |
10 | Bar length | 550mm |
Features and functions
1. Rainproof housing, #304 stainless steel
2. CNC stamping and laser drilling, presenting a novel and elegant appearance
3. Innovative and unique mounting surface ensures simple and convenient installation for system integrators;
4. Direction can be set as single-direction or bi-direction
5. Direction indicator
6. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc. (Access controller needed)
7. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically;
8. With backup battery, complying with fire safety requirements.
9. The mechanism is equipped with an automatic regulated hydraulic buffer device. There is no noise and impact when running.
10. Dual-bearing device, keeping the gate in balance when there is external force.
