Intelligent Tripod security Turnstile Gate for Access Controller Opening

Intelligent Tripod security Turnstile Gate for Access Controller Opening

  • Intelligent Tripod security Turnstile Gate for Access Controller Opening
  • Intelligent Tripod security Turnstile Gate for Access Controller Opening
Intelligent Tripod security Turnstile Gate for Access Controller Opening
Product Details:
Place of Origin: China(Mainlan)
Brand Name: RS Security
Certification: ISO,FCC,SGS,RoHS,CE
Model Number: RS 118
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: 10000usd
Packaging Details: Wooden Box
Delivery Time: 2-7workdays
Payment Terms: TT,
Supply Ability: 3000pcs/month
Contact Now
Detailed Product Description
Series: Tripod Turnstile Product Name: Bridge Circular Tripod Turnstile
Modal: RS 118 Brand: RS Security
Material: 304 Stainless Steel Size: 1200*280*980mm
High Light:

tripod turnstile mechanism


tripod turnstile gate


Security Mechanical Tripod Automatic Turnstile for Pedestrian Access Control

Series:Tripod Turnstile
Product Name:Luxury Bridge Tripod Turnstile
Model:RS 118
Material:304 or 316 Stainless Steel
Protection grade: IP54
Luxury Bridge Tripod Turnstile service: OEM/ODM
Luxury Bridge Tripod Turnstile direction: Bi-direction
Luxury Bridge Tripod Turnstile Colors: Bright silver grey and black, or custom


Product Discription

Luxury Bridge Tripod Turnstile RS 118  is integrated with mechanism, electric and micro-controller and various kinds of identification technologies, compatible with IC, ID, barcode, fingerprint reader and so on to provide intelligent control and management to flow control. Durable, anti-rusty. Provide orderly passage to people, anti-illegal entry or exit, smooth operation, low noise. Arm drops off in condition of emergencies.
Luxury Bridge Tripod Turnstile RS 118  is widely used in bus station, port, subway, factory, mansion, residential area, hotel, and companies and so on any place that requires a smart flow control.





304 stainless steel





Net weight




24V DC brush


Communication interface



Transit speed

30-40 people/minute


Close and open time



Clear passage width



Number of led lamp



Input voltage

220V AC220±10%


Are length



Arm diameter



Cooler fan






Service life

5000,000 times


Input interface

Relay signal, 12V level signal,


Work environment

Indoor and outdoor (shelter)



RS 118



1. Reliable and durable, low noise and stable operation, adapt to varied situation;

2. Standard electrical interface, various card reader acceptal to our wing gate & can be (remote) controlled by computer, single/Double Directional Optional which can be controlled by both ways or single way( can be mechanically set by the buttons on built-in control panel);
3. Gate open automatically when power off to the request of fire protection, and automatically closes when power on;

4. The wing gate installed Infrared sensor interfaces, could be expanded to Infrared testing function.
5. Breakdown Self-checking and alarm indication, easy for maintenance and using;

6. The wing gate arm will automatically locked until opening signal is received, motor will stop working in case of the wing encounter of obstruct; ;
7. Anti illegal entering alarm: Light and sound alarm is generated when the illegal invasion and the tail followed;

8. Automatically reset function: It will automatically lock if the pedestrian hasn't pass through the channel in the pre-set time after the opening. The passing time is adjustable;

9. Passage in both directions electronically controlled. The pedestrian retractable barrier is available in Normally Open (N/O) or normally Closed (N/C) mode. In N/O the speed gate provides an always open walkway in rest position and will only close at unauthorized entry or tailgating attempts;
10. Driving Mechanism: The wings are moved by mechanical arms. The arms are rotated by a torque shaft connected to the drive unit. The drive unit is a DC motor working in conjunction with a bi-directional encoder. A microprocessor control system guarantees the precise movement and positioning of the wings;

11. Method of Operation: ON receiving a signal from the access control system, or push button, the wings open. If an unauthorized person tries to tailgate or attempts to enter from the opposite direction, the system detects the unauthorized passage and activates the in-built alarm system;
12. Status Lights: 90mm dia. LED display status lights flush mounted within the speed gates lid top face. Upon authorization a Green arrow will illuminate in the direction of passage authorization whilst in the opposite direction a Red Cross symbol will illuminate to indicate the unit is not available for use or is already in use.
13. Optional:
1) Counter and counter display
2) Access controller or card reader
3) Key by-pass



1.Q:Can I know the difference between automatic type and manual type?
A:First, for manual type, it doesn't have electric control device. For automatic type, it can be compatible with card, finger print,barcode etc. Second, for manual type, it is single direction.
2.Q:Do you have any MOQ limit for tripod turnstile?
A:No, we don't have MOQ limit for tripod turnstile.
3.Q:What is the lead time for tripod turnstile?
A:For 10 units, we need 5-7 working days. For 20-50 units, we need 15 working days. For 100 units, we need 25 working days.
4.Q:Can I buy the mechanim of tripod turnstile?
A:yes, if you need, we can offer you.
5.Q:Do you offer guarantee for the products?
A:Yes, we offer one year warranty for the whole unit product and the accessories.
6.Q:Is OEM,ODM  available?
A:Yes, it is available.
7.Q:Does the price include card reader and access control?
A:No. If you need, we can offer you the price.
