Waterproof Luxury Waist Height Turnstiles Used Tripod Turnstile Automatic
Specifications
Tripod turnstile for different kind systems
Model: RS 418
1.MOQ:1 piece
2.turnstile manufacturer,factory price
3.OEM welcome
Automatic turnstile gate made of 304 stainless steel from China manufacture
Introduction
Appearance GB(304) stainless steel plate stamping molding,nice shape,rust-proof and durable
.Besides foreign standard electrical interface,bar code,ID card,IC card reader can be integrated
in the equipment.
They are used most commonly in train stations, airports, theme parks, museums and office lobbies.
1.The material of tripod turnstile is 1.5mm stainless steel,laser cutting machine.
2.The overall appearance was a round,simple and fashion.
3. Chassis with anti-fingerprint surface treatment, long-term use will not have fingerprints generated
; eight years can be maintained
4.Chassis base with black titanium stainless steel base, enhance the overall aesthetic effect.
5.Brake lever is used in stainless steel pipe diameter 38 pack silicone, can effectively prevent the
use of the outdoor hot, crash.
6.Led screen showing greeting, card swipe person's name can be displayed
|
Technical Parameters
|
| Framework |
304(standard)/316 grade stainless steel
|
| Dimensions |
Tripod turnstile:1200*280*980mm
|
|
Package dimension:1050*350*1050mm
|
| Rod length |
510mm
|
| Weight |
70kg.
|
| Operating Mode |
one-way or two way control
|
| Power supply voltage |
AC220 ± 10%V, 50HZ
|
| Interface |
standard RS485/distance≤1200m or TCP/IP.
|
| Gate opening time |
0.2 second
|
| Transit speed |
30-40 persons per minute
|
| Working environment |
indoor or outdoor
|
| Temperature |
-10 Celsius to 50 Celsius
|
| Relative humidity |
:≤90% no condensation
|
|
Main Features&Function
|
|
1. Available in single walkway or bi-directional passage.Both directions can be set as
controlled mode or free mode.
|
|
2.Self-recovery function:the machine will recovery automatically with invalid counting if
passage is not completed within pre-set time(5 seconds default,adjustable by software).
|
|
3.Multi-alarm function:When arms are pushed by force illegally,alarm will be triggered
automatically and the center rotor will be set locked(the duration of the alarm and lock is
adjustable by software).
|
|
4.Automatic-rotation function:once an open signal is given,the center rotor will rotate
automatically.
|
|
5.Anti-reverse-rotation function:reverse rotation will be forbidden once the arms have
moved to pre-set degree from home(adjustable by software).
|
|
6. Emergency escape function:the obstacles will open automatically by pressing the
emergency button which can be remote-controlled whether the power is on or not.
|
|
7.Smart card reader compatible with a variety of card such as IC and ID card.
|
|
8.Can be expanded to automatic identification system,realizing function to access
control,
pedestrian flow control,attendance check or fare collection.
|
| 9.Equipped with international standard electrical interface,can be easily integrated with other R/W device,also can be controlled and management through remote supervision computer. |
|
10.Control panel with count and LED digital function.
|
|
11.Optional traffic-light: A Red Cross symbol will illuminate to indicate unit is not available
for pass, and a green arrow indicate the direction of allowable pass.
|
