Tripod Barrier

Product Details:

Place of Origin:	China
Brand Name:	SH
Certification:	CE
Model Number:	SH113
Dimension:	1200280990mm
Arm Length:	300-600mm
Material:	304 stainless steel
Working temporature:	-40 to 70 ℃
Communication Connection:	RS485 Communication
Working voltage:	AC220±20%,50HZ
Drive Motor:	DC brushed motors (24V)
Passing Speed:	40 Person/min

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	300-800 USD
Packaging Details:	in Wooden Box
Delivery Time:	within 7 working days
Payment Terms:	T/T
Supply Ability:	3000 units/month

Contact Now

Detailed Product Description

High Light:

Intelligent Turnstile

tripod turnstile

3-arm turnstile

Hight Quality Tripod Turnstile Barrier Gate

Product Descriptions:

(1) When power off, it will be dropped the arm to the request of fire protection (default) or free pass Mode (option). When the power is on again, the arms can also lift by hand.

(2) The equipment is integrated with delicate mechanical transmission,

microprocessor control, and various read/write techniques. It can be used for intelligent control and management of the passage after equipped with different read/write devices.

(3) The system is provided with a standard electric interface and is easily integrated into the equipment with read/write facilities such as magnetic card,

bar code card, ID card and IC card. As a result, an orderly and civilized passage is provided for the personnel in and out, and illegal personnel can be barred. At the sametime, a special fire control interface is equipped in the system to meet the requir ement of fire control passage, so that a rapid down rod control may be realized in emergency for

APPLICATIONS:

Typical areas of application are: office building, governmental buildings, banks, hotel, super market ,and park.

FUNCTION SPECIFICATIONS:

1,Both directions can be set as controlled mode or free mode

2,Reset automatically: Go signal will be cancelled if passage through is not completed within preset time. The standard default is 5 seconds (time adjustable by software)

3,When power off, it will be dropped the arm to the request of fire protection

(default) or free pass mode

4,Anti backup function to prevent reverse rotation once the mechanism has move 60 degree from home

5,Optional indication of outside LED counter

6,With interface of switch of relay,compatible with all the access controller

7,Alarm time and numbers adjustable; With RS232/ RS485; Extendable with CAN BUS and Ethernet

8,Anti backup function to prevent reverse rotation once the mechanism has move 60 degree from home

9,Equipped with free control software for human machine interface & control command SDK

FRAME WORK SPECIFICATIONS

1,Framework: 304(default) /316 Grade Stainless Steel

2,Thickness of ply: 1.5mm (default)/ 2.0mm

3,Finish: Brushed surface (default)/ polishing surface

4,Shell size: 1200*280*990mm (Standard)

5,Arm’s length : 500-650mm; Arm diameter: 35-48mm

6,The maximum tolerance of the pole:70 Kg.

7,Working driving force of the pole: 3Kg

8,The inductive card reader dimension: equipped with the standard mounting brackets, or tailor made
