Place of Origin: | China(mainland) |
Brand Name: | RS Security |
Certification: | ISO,FCC,SGS,RoHS,CE |
Model Number: | RS 116-1S |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | 2000USD |
Packaging Details: | wooden box |
Delivery Time: | 3-8workdays |
Payment Terms: | TT |
Supply Ability: | 3000pcs/month |
Series: | Swing Barrier | Product Name: | VerticalSwing Barrier |
---|---|---|---|
Model: | RS 116-1S | Brand: | RS Security |
Material: | 304 Stainless Steel | Size: | 430*330*980mm |
Highlight: | electric swing gates |
Supermarket Swing Gate Application
It can be used in many places, especially for the place where have a large stream of people. Normally, it is
mainly used to welcome the arrival of the customers, to catch the eyes of customers, and to provide a safe
and fashionable access control solution.
Dimension | diameter 168*1050mm |
Stainless Steel Specification | Body: SS304 |
Swing arm length | 600-900mm |
Power Supply | AC110V±10V,60Hz / AC220V±10V,50Hz |
Swing direction | single |
Swing arm rotation angle | 180 degree |
Passing Speed |
40 persons/min (normal open) 30 persons/min (normal close) |
Response Time | 1s |
Input Interface | +12V electrical signal or DC impulse signal with width >100ms |
Communication Interface | RS485/relay signal |
Operating Temperature | -15°C ~ 50°C |
Related Humility | <=95% |
Package | Paper Carton/Wooden Box |
Features:
. Aesthetics
. Elegant design
. Rounded forms and glass obstacle
. Quality of finish
. Bright, modern pictograms
. Security
. Secure and reliable detection system
. Retractable obstacles allow fast closure of the walkway
. Mechanical locking, preventing forced opening
. Protection of users
. Numerous electronic safety cells
. Permanent control of the movement of the obstacle
. Protection against finger entrapment and physical injury
. In case of emergency, the passage is opened by intrinsic mechanical energy
. Reliability
. Long lifecycle and reduced operating costs
