Security Automatic Pedestrian Swing Barrier Gate Government Passage Turnstiles
With the improvement of living standards, people's demands for aesthetics are also getting higher and
higher. In some high-end locations, the appearance and function of the traditional pedestrain turnstile is
far from meeting our requirements. RS 316-2 swing gate series products adopt the international standard
SUS 304 stainless steel, with a glass panel at the top, beautiful shape, rust resistance, and durability. .
Flexible support for fingerprint, face, vein, RF card and other identification terminals, and form a one-stop
security management platform with attendance, access control, ladder control, parking, and consumer
systems to provide civilized and orderly access for personnel. The access method can also eliminate the
entry of illegal personnel; in the event of an emergency, it ensures unimpeded access and facilitates
timely evacuation.
| Limits to use |
| Leaf length (mm) |
600 / 900 |
| Min/max width of passage clearance (mm) |
1,250 / 1,850 |
| Max gate-leaf opening (°) |
90 |
| Technical features |
92 |
| Protection rating (IP) |
40 |
| Power supply |
(V - 50/60 Hz) 120 - 230 AC |
| Motor power supply (V) |
24 DC |
| 90° opening speed (s) |
1 |
| Power (W) |
120 |
| Operating temperature (°C) |
-20 ÷ +55 |
Features
1. Door will keep opened automatically while power cut off.
2. Direction of through is adjustable, one-way, bi-direction.
3. LED direction indicator
4. Anti-pinch function
5. Anti-tail, prevent people follow pass without verified
6. Use super capacitor instead of backup battery for gate open with electric cut off, without shipping
problem with battery.
7. Prevent wrong direction pass, go through wrong direction will be alarm by beep
8. Option RFID access controller, fingerprint reader, facial identify reader, qr code reader, barcode
reader, consume system.
