Place of Origin: | China(mainland) |
Brand Name: | RS Security |
Certification: | ISO,FCC,SGS,RoHS,CE |
Model Number: | RS 288 |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | 2000USD |
Packaging Details: | wooden box |
Delivery Time: | 3-8workdays |
Payment Terms: | TT |
Supply Ability: | 3000pcs/month |
Material: | Stainless Steel | Wing Color: | Red |
---|---|---|---|
Size: | 1400*300*990mm | Protection Grade:: | IP44 |
Colors:: | Bright Silver Grey And Black, Or Custom | Flap Gate Service:: | OEM/ODM |
Highlight: | automatic gate barrier system |
Access flap barriers Finish: Brushed (default) / Snowflake / Paint (optional, color customizable), High
quality brushless DC motor driving baffle Flex, Very good synchronism, Smooth operation, No jitter,
Low noise, Access Fast; baffle opening and closing speed and delay time adjustable.
Specification:
Brand | RS Security Co.,Ltd | ||||||||||
Item No. | RS 288 | ||||||||||
Housing Material | 304 stainless steel | ||||||||||
Dimensions | L1000 x W300 x H1000mm | ||||||||||
Maximum Passage Width | 600mm | ||||||||||
Power Supply | AC220V±10%,50HZ | ||||||||||
Motor Voltage | DC24V | ||||||||||
Flap Opening/Closing Time | 0.2S | ||||||||||
MCBF | 5 million cycles | ||||||||||
Transit Speed | 35 persons/min | ||||||||||
Operating Environment | Indoor/outdoor (Shelter) | ||||||||||
Operating Temperature | -30°C ~ 60°C | ||||||||||
Operating Humidity | ≤95% no condensation |
Description:
1, With function of self-examine and alarm, it is convenient for maintenance and use.
2, Being able to program running status by the small keyboard in the main board
3, Preventing pedestrians or bicycle from being nipped and from hurt, the force of the
Pole is less than 2Kg
4, Sound or light alarm function
5, Poles are automatically locked until a opening signal is received.
6, Poles synchronization
7, Automatically reset function: It will automatically lock if the pedestrian hasn't pass
through the channel in the pre-set time after the opening. The passing time is adjustable.
8, Channels automatically open when power off, and automatically close when power on.
