Children snail wing brake Flap Barrier Gate with Silicone protective flap

Children snail wing brake Flap Barrier Gate with Silicone protective flap

Product introduction:

Children's flap barrier  the company specializing in the development and making. The arc-shaped structure make it seems beautiful,the colour is the car lacquer that bake process,double waterproof treatment.Can be installed in indoor, outdoor with shed, applicable to restrict the passing rate of the place, has the count, attendance, current limiting function.

Feature of the product:

Children's wing brake, the company specializing in the development and making.

1. Stainless steel box, box-type bevel shape, novel and beautiful, durable.

2. Waterproof, sunscreen, anti-temperature, anti-cold.

3. Access Prompt function:Red and green light prompt the passing information.

4. The programmable gates control state, with a variety of operating modes you can choose, you can set a

one-way or two-way control

5. Compatible IC, ID, magnetic card, bar code card, and other control equipment.

6. Power failure emergency function after power channel automatically open, closed automatically after

 power-on, to meet the special needs of the user and the fire safety requirements

7. The control panel with counting function, LED digital display function (optional)

8. The standard input and output interface, is the best choice for system integrators

9. With automatic reset function, gate, not prevailing within the stipulated time, the system will automatically

 cancel the access permissions of the user.(the standard is gate turns on 5 seconds will be automatically reset)

10. Pinch, anti bumps function, Blockage when in the process of the swing arm reset within a predetermined

 time, click stop working automatically, the default reset again after a delay, and the intensity is very small(2kg)

11. Sound, light alarm function: with trespassing, trailing alarm

12. Scour protection function ,when the gate signal is not received, the stick is automatically locked

13. Fault detection and alarm function, user-friendly maintenance and use

Technical:

1. Structure: frame structure/standard stainless steel shell

2. Production: full CNC laser cutting machine production

3. Dimensions: length 1000 × width 300 × height 760 (mm)

4. Stainless steel thickness:1.5mm

5. Maximum channel width :550-600mm

6. Weight: 140Kg

7. gate opening time: 0.2 seconds

8. prevailing speed: 30 people / min

9. Communication Interface: Standard RS485 interface, distance ≤ 1200 meters or TCP / IP

10. Power: 50W

11. Power supply voltage: AC220 ± 10% V, 50HZ

12. drive motor: brushless DC motor (24V)

13. normal life: 3,000,000

14. LED indicator: 2

15. reader windows: 2

16. access speed :30-40 / min

17. power on the prevailing state required time: 3 seconds

18. failure automatically reset after time: 10 seconds

19. input interface: dry contact signal or +12 V level signal or pulse width ≥ 100ms DC12V pulse signal, driving

 current ≥ 10mA;

20. Working environment: indoor, outdoor (with shed)

21.Temperature: -10 ℃ ~ 50 ℃ Relative humidity: ≤ 90%, no condensation.
