Shenzhen Turnstile Technology Co., Ltd.
High quality, Best service,Reasonable price.
 |
| Place of Origin: | China |
| Brand Name: | GlobalKeyAccess |
| Certification: | CE |
| Model Number: | GKA3021 |
| Minimum Order Quantity: | 10 pcs |
|---|---|
| Packaging Details: | Wooden case |
| Delivery Time: | 5 working days after payment receipt |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 500 pcs per month |
| Application: | Barrier Gate Control | Reader Type: | 868~928MHz UHF RFID Reader |
|---|---|---|---|
| Reading Distance: | 3 To 9 Meters | Tag Type: | Passive Tag/sticker |
| Communication: | TCP/IP | Working Mode: | Online Or Offline |
| User Capacity: | 20,000 | Events: | 150,000 |
| High Light: | vehicle parking management system,car access system |
||
Auto Parking Lot Barrier Gate Vehicle Access Control System 868 ~ 928MHz UHF RFID Reader
Specifications:
|
Communication type |
TCP/IP |
|
Network type |
LAN network |
|
Working mode |
Online or Offline |
|
Parking barrier types |
2.5~3 meter boom, speed @ 1.6~3Sec 3~6 meter boom, speed @j3~6Sec 3~45 meter folding arm, speed @ 4~6Sec 3~4 meter half fencing arm, speed @4~6Sec 3~4 meter full fencing arm, speed @4~6Sec |
|
Color |
Orange(021C), blue(2945C), yellow(803C) |
|
Access points |
No limit, support multiple entrance & exit |
|
Monthly reader |
2 readers, 1 is for normal use, 1 is for Long range RFID reader for VIP customers |
|
Readers signal |
Wiegand 26/34 |
|
Reader cable length recommendation |
Less than 50 meters |
|
Support IP camera |
Yes, plug in the switch or router |
|
Snapshot of manual open barrier |
Yes, to prevent secretly release vehicles |
|
Support image capture at entrance & exit |
Yes |
|
LED dimension |
304*76mm, red color |
|
Parking rate types |
Programmable in software |
|
Report of software |
Hourly fee charged list & aggregation Monthly fee charged list & aggregation Manual open inquiry |
|
Demo software with source code/SDK |
Provided |
|
Database type |
SQL2005, 2008 |
|
Power consumption |
12V5A(readers, LEDs should be considered) |
|
Dimension |
180*110mm |
|
Working temperature |
-30℃~+80℃ |
|
Humidity |
5~95% |
|
Certification |
CE, EMC |
Description:
Process of parking revenue control system:
1. Driver drives a vehicle approaching the barrier gate(the tag/sticker attaches on windscreen),
2. The EPC G2 RFID reader detects the tag/sticker when it is in detection range,
3. The barrier gate will be opened/closed automatically,
4. The vehicle enters or exits,
5. All access history is stored in hardware(controller),
6. The data stored in controller/control board could be uploaded to PC when connected.
Main features:
Card capacity: up to 20,000
Events storage: up to 150,000 pcs
No computer monitoring needed
Automatically open/close the barrier gate
Hand free process for drivers’ in & out
Speed up the vehicle flow at the entrance or exit
Antenna detection distance range from 3 meters to 20 meters
All parking access control data is stored
Applications:
| Vehicle access control system | Barrier gate access control, parking lot control |
Competitive Advantage:
Manufacturer of the vehicle access control system
Could handle sharp increase orders
Friendly used software pages
OEM production is accepted
Long Range UHF RFID Car Parking Barrier Gate Access Control System IP based
