Place of Origin: | China |
Brand Name: | TDZ |
Certification: | CE |
Model Number: | TDZ-Y228 |
Minimum Order Quantity: | 1 piece |
---|---|
Price: | USD 500 -2000 / Piece |
Packaging Details: | paper carton and wooden cases |
Delivery Time: | 3-4 working days |
Payment Terms: | T/T, Western Union, MoneyGram, L/C, D/A, D/P |
Supply Ability: | 200 pieces / month |
Structure: | Frame Stainless Steel Housing | Turnstile Material: | 304 / 316 Stainless Steel (optional) |
---|---|---|---|
Dimension: | 1400*300*1000mm | Normal Lane: | 550mm |
Driving Motor: | Brushless DC Motor (24V) | Weight: | 90kg |
Gate Openiong Time: | 0.2 Seconds | Pass Speed: | 40 Person/min |
High Light: | Flap Barrier Turnstile,Pedestrian Turnstile Gate |
|
|
|
Material | 304/316 stainless seel (optional) |
Fishing | Brushed surface (standard) / Polishing surface |
Dimension | 1400*300*1000mm |
Normal channel width | 550mm |
Drive motor | Brushless DC motor (24V) |
Power supply | AC220 (110) ± 10%V,50Hz |
Working life | 3,000,000 times |
Communication Interface | RS485 / RS232,Ethernet |
Transit Speed | 20 - 35 passage / minute |
Work Environment | Indoor / Outdoor (Shelter) |
Use Place | Station,park,apartment,school,factory,bank,building |
|
1.Fault detection and alarm functions, easy to use and maintenance.
2. The running status can be programmed and controlled with the built-in keyboard on the main board.
3. Mechanical antipinch function. If the gate meets resistance in the reset process, motors will stop working automatically within the prescribed time and reset again after the default delay (till fully reset).
4. Anti-breakthrough function. The gate is locked automatically until opening signal received
5. Synchronization functions (for dual gate equipments).
6. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds),the system will cancel the authority of the current user automatically.
7. Gate can be set as normally open or normally closed.
8. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc.
(Access controller needed)
9. Direction can be set as single-direction or bi-direction.
10. LED direction indicator.
11. Gate auto opens when power off and auto close when power on, complying with fire safety requirements.
12. Alarm function, in case of illegal intrusion and reverse intrusion, etc.
13. Counter function (optional).
14. Support infrared photocell for anti-pinch and reset function (optional).
|
Our service
|
1. One -stop security solution provider, can help you save time and costs. |
2. Good quality with competitive price, offer OEM and ODM service. |
3. Professional technical supports and great after-sales service. |
4. Custom design shape and logo,for large amount, custom logo available for free. |
5. Fastest delivery and safe shipping way. |
6. Warranty: One year Warranty, from the date of delivery, a lifetime technical support. |
7. Feedback quickly: 24 hours online service and reply your inquiry within 8 hours. |
8. We could provide Online supports for you when need supports on testing. |
Payment Terms |
TT, Western Union, Cash |
Shipping Way: |
1. Fast way: by express courier,door to door, such as DHL, FedEx, UPS, TNT, EMS. by air, to airport |
2. Cheap way: by sea shipment. |
