Automated Full Height Turnstiles Gates With Security Alarm And Card Reader RS485

Automated Full Height Turnstiles Gates With Security Alarm And Card Reader RS485

  • Automated Full Height Turnstiles Gates With Security Alarm And Card Reader RS485
  • Automated Full Height Turnstiles Gates With Security Alarm And Card Reader RS485
Automated Full Height Turnstiles Gates With Security Alarm And Card Reader RS485
Product Details:
Place of Origin: China(mainland)
Brand Name: RS Security
Certification: ISO,FCC,SGS,RoHS,CE
Model Number: RS 997
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: 13000usd
Packaging Details: wooden box
Delivery Time: 3-8workdays
Payment Terms: TT
Supply Ability: 3000pcs/month
Contact Now
Detailed Product Description
Seires: Half Height Turnstile Product Name: Half Height Turnstile
Model: RS 997 Brand: RS Security
Material: 304 Stainless Steel Size: 1400(L)*280(W)*1000(H)mm
High Light:

automatic systems turnstiles


security turnstile gate


Automated Full Height Turnstiles Gates, Card Reader Turnstile System



product name:Half-Height Turnstile

RS 997

The unique two way reversal prevention

Shock-proof and automatic reset

Low Noise and run smoothly

The device will be mechanical, electronic, microprocessor control and a variety of reader technology organically integrated. Read and write by configuring the various devices, the use of reliable security protection and real-time alarm system with directional interface, to achieve a common coordination channel of intelligent control and management.

Appearance of stainless steel equipment, metal forming, nice shape, rust-proof, durable, and outside a standard electrical interface, can easily bar code card, ID card, IC card reader integrated in the device, to provide access civilized, orderly passage way, and would also prevent illegal workers out; Addition, the system also designed to meet the fire safety features required in an emergency, to ensure unimpeded access for officers to evacuate.

1. Has failed self-test function, user-friendly maintenance and use.

2. Has multiple operating modes to choose from, you can limit two-way card reader, card reader can also be side, cut the line in another direction, while the reader, free movement in another direction.

3. Has a free passage-way power, auto power lock feature to restore order quickly in an emergency evacuation of personnel.

4. When a valid card read, just after the pedestrian entered the door to gently push switch, automatic reset, both directions, the four door is always closed, turning 90 degrees every time the turnstile.

5. Has a automatic reset function. When the reader, the passage in the required time does not pass, the system will automatically cancel the access privileges of those in this passage, and limit the passage of time set by the managers themselves.

6. Uses a unique drive system, the gates locked at zero, unlock more accurate and reliable.


7. Has a uniform, standard external electrical interface with a variety of read-write device with mounted, easy system integration, and computer remote control through the management and administration.

8. With 485 days of remote control gate, closing functions to meet customers' specific requirements and fire safety requirements.

9. Automatic direction of the prevailing number of traffic statistics, and visual LED (optional. Presented to the managers, so that managers of a number of well known direction of movement.

10. With a clear indication of the direction of movement, access to visual LED indication who can pass or closed to traffic.

11. Has a card reader with memory and without memory, and the user according to their needs through the motherboard keyboard settings.

12. Set by software, may limit the total number of sites within, in order to meet the special needs of some special occasions.

13. The whole system running smoothly, low noise;

Structure: The product shape 304 stainless steel sheet, stainless steel pipe using 202 metal forming, rust-proof, durable, easy to use the device, no maintenance.


Dimension: 1400X1100X1150mm

Brake rod length: 600 (mm)

Weight: 100KG about

Brake lever steering: One-way, two-way (optional)

Working environment: Indoor, outdoor (preferably frame awning)




1) Supply voltage: AC220 ± 10% V, 50Hz

2) Drive motor: DC 24V/100W

3) Operating temperature: -15C ~ 60 C

4) Relative humidity<= 90%, no condensation

5) input: 12V level signal or pulse width> 100ms 12V pulse signal drive current> 10mA

6) Communication Interface: RS485 electrical standards,

7) Communication distance: <=1200M

8) pass speed: 30 / min (open mode), 20 / min (closed mode)

9) gate opening and closing time: 2 seconds


Scope of application:


For one-way or two-way flow control the import and export channels.

Stations, terminals, attractions import and export channel

Exhibition, swimming pool and other check-in channel

Area, factories, import and export enterprises and attendance, access control, consumption management

Special access control.


Traffic type


Automated Full Height Turnstiles Gates With Security Alarm And Card Reader RS485 0Automated Full Height Turnstiles Gates With Security Alarm And Card Reader RS485 1






304 stainless steel

Input voltage

220V AC220±10%



Are length


Net weight


Arm diameter



24V DC brush

Cooler fan


Communication interface




Transit speed

30-40 people/minute

Service life

5000,000 times

Close and open time


Input interface

Relay signal, 12V level signal,

Clear passage width


Work environment

Indoor and outdoor (shelter)

Number of led lamp



RS 997



Competitive Advantage:


Our advantage:

  • We are a leading manufacturer of turnstile and speed gate in China.
  • We focus on pedestrian turnstile gates.
  • We keep stock for regular products and we can support small orders. Usually, our lead time is just 3 days.
  • Design products according to customers’ requirements.
  • Credibility: We are SGS certificated Supplier. Our customers are located over 50 countries
  • Gratitude: We cherish the business chance you give us and return you with quality products and good service.
  • Professional: We have been in this business for more than 8 years. We have a strong professional team with various experiences.
  • We keep doing new product development. Our goal is to enhance our competitive capacity constantly.
  • Price: very competitive price and good quality products
  • Quality: we do 100% inspection before the shipment.
  • Promise: we are always ready to take the responsibility if any loss caused to our customer due to our mistakes.
